SKU
HOOL-X12.1DHE
Nominal Diameter
12″ / 304.8mm
Nominal Impedance
1+1ohms
RMS Power Handling
4000W
MAX Power Handling
6000W
Sensitivity (1w/1m)
87dB
Frequency Response
20-500Hz
Recommended Lo Pass Crossover
80Hz
Voice Coil Diameter
4” / 99.8mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
Carbon Fiber
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Gloss Black with Machined Aluminum
Magnet Material
Ferrite
Magnet Weight
500 OZ
Displacement Volume
4.8L / 0.169ft3
Sealed Internal Volume
17L / 0.6ft3
Sealed Box Output Response
41Hz
Ported Internal Volume
42.5L / 1.5ft3
Port Size *Square (W x H x Long)
1.52″ x 12.28″ x 31.82″ / 38.5 x 312 x 808.2 mm
Port Tunning Frequency
30Hz
Ported Box Output Response
25Hz
Overall Diameter
12.64″ / 321mm
Overall Depth
11.6″ / 295mm
Front Mount Baffle Cutout
11.2″ / 285mm
Mounting Depth
10″ / 255mm
Motor Diameter
9.96” / 253mm
Product Weight (lb)
87.5
Dimensions L x W x H (Inches)
15 x 15 x 14
M/C Weight (lb)
87.5
M/C Dimensions L x W x H (Inches)
15 x 15 x 14
M/C Qty
1
Sold in
Single
DS18 HOOL-X12.1DHE
HOOLIGAN 12″ High Excursion Car Subwoofer 4000 Watts Rms 4″ Dvc 1-Ohm
Experience a new level of bass performance and power with DS18’s HOOL-X12.1DHE! The HOOLIGAN 12” High Excursion Car Subwoofer has been the top choice for enthusiasts and competitors alike, and now, it’s back with a vengeance.
The HOOLIGAN is built for power and durability. The redesigned long throw pole, larger spider, and high excursion surround, helps lower the HOOLIGAN’s FS (Resonant Frequency), making it even louder at subsonic frequencies. With an FS of 26, this subwoofer guarantees impressive low frequencies all the way down to 20Hz. Its high-powered 4″ Black Aluminum voice coil can handle 4000W RMS and 6000W MAX power, making it perfect for heavy-hitting competition bass.
Versatility is key, and the HOOL-X12.1DHE can adapt to various enclosure types. Whether you prefer 4th orders, 6th orders, ported boxes, or large sealed boxes, this subwoofer will thrive in any setup that has enough room.
This version of the HOOLIGAN boasts a nominal diameter of 12″ (304.8 mm) and a nominal impedance of 1+1 OHMS. With a sensitivity of 87 dB and a frequency response ranging from 20Hz to 500Hz, this subwoofer ensures every beat is reproduced with staggering depth and precision.
DS18’s HOOLIGAN 12″ High Excursion Car Subwoofer is the ultimate choice for car audio enthusiasts seeking extreme bass and massive power. Its unmatched performance, cutting-edge design, and versatility make it a must-have for any ground shaking audio system.
$594.96
